Vertical Floor Mounted AHU (DX Type and Chilled Water Type)

Overview

RANGE: 1000 CFM to 20000 CFM
SALIENT FEATURES: Having low noise break out, the Vertical AHU Air Handling Unit provides fresh quality air to create a comfortable relaxing or working environment. Built from a strong aluminum profile construction, this AHU - Air Handling Unit provides an easy to install and easy to commission ventilation system with convenient access to maintenance areas.
Designed to Fit Within Recess - Easily Concealed
Low Noise Break Out
Cost Effective Solutions
APPLICATION AREAS: Vertical Air Handling Unit are preferred to many Restaurants, Retail Stores, Fitness Clubs, Hotels and House Developers across the country.

Unit Construction

Airmake air-handling units are based on a self-supporting frame structure. Their modular casing design, with individual compartments comprising various functional assemblies, ensures that each unit matches individual application requirements perfectly.
Although materials may vary with the unit size and application, all AHUs are of a similar construction; namely an outer framework of posts, assembled using knock in corners, into which double skin, insulated enclosure panels are fitted to form a rigid, airtight compartment.
Double skin insulated panels are available in 25mm and 42mm thick with uniform density of 38-42 Kg/m3. Various options are available such as pre-coated color galvanized sheets, plain galvanized sheets, SS304 & SS316 sheets in various thickness for inner & outer skin.
Smaller units can be supplied as a single section, whereas larger units are usually supplied in modular form, split into manageable sections for final assembly (bolting-up) on site.
AHU sections are generally supplied with a sturdy channel base support frame, complete with lifting holes to facilitate crane age.
All internal components, such as the fan and motor assembly, are built in to the unit sections and are provided with access or removable panels, if necessary, to facilitate maintenance and removal.
All forms of component commonly utilized in air handling equipment can be incorporated into the design such as filters, heaters, cooling coil, heating coil, humidifiers, attenuators, air damper etc.

Functional Assemblies

Casing Single Skin/Double Skin 25 -50 mm thick
Fan Motor Section
Cooling Coil Section
Filter Section
Drain Pan
Other Accessories

Request a Quote

Horizotal Floor Mounted AHU (DX Type and Chilled Water Type)

Overview

RANGE: 1000 CFM to 50000 CFM
SALIENT FEATURES: These units have wide application in the handling of process air in drying, coating system in pharmaceutical , chemical and other industries.
Extremely strong and durable aluminum framework
Sturdy constructed Unit Base frame having lifting holes
Available for High Static application
Available in different configurations of functional assemblies
Internal coving sections
Single and double tier construction

Unit Construction

Airmake air-handling units are based on a self-supporting frame structure. Their modular casing design, with individual compartments comprising various functional assemblies, ensures that each unit matches individual application requirements perfectly.
Although materials may vary with the unit size and application, all AHUs are of a similar construction; namely an outer framework of posts, assembled using knock in corners, into which double skin, insulated enclosure panels are fitted to form a rigid, airtight compartment.
Double skin insulated panels are available in 25mm and 42mm thick with uniform density of 38-42 Kg/m3. Various options are available such as pre-coated colour galvanized sheets, plain galvanized sheets, SS304 & SS316 sheets in various thickness for inner & outer skin.
Smaller units can be supplied as a single section, whereas larger units are usually supplied in modular form, split into manageable sections for final assembly (bolting-up) on site.
AHU sections are generally supplied with a sturdy channel base support frame, complete with lifting holes to facilitate crane age.
All internal components, such as the fan and motor assembly, are built in to the unit sections and are provided with access or removable panels, if necessary, to facilitate maintenance and removal.
All forms of component commonly utilised in air handling equipment can be incorporated into the design such as filters, heaters, cooling coil, heating coil, humidifiers, attenuators, Air damper etc.

Functional Assemblies

Casing in Single Skin/Double Skin 25 -50 mm thick
Fan Motor Section
Cooling Coil Section
Heating Coil Section
Filter Section with Pre, Fine and Hepa Filter as per customer required
Drain Pan with insulated
Return, Fresh Air Damper
Mixing Box Section
Dehumidification
Other Accessories
